Roscoe 7 Gen 4

Frame
Alpha Platinum Aluminum, tapered head tube, ZS headset, internal derailleur & dropper post routing, ISCG 05, threaded BB, UDH, 148x12mm thru axle
Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 150mm travel

Wheels
Hub front
Shimano TC500 alloy, centerlock, 110x15mm thru axle
Hub rear
Shimano TC500 alloy, centerlock, 148x12mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
*Rim
Size: S, M, ML, L, XL
Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve
Size: S, M, ML, L, XL
Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
*Tire
Size: S
Bontrager Gunnison Pro XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40''
Size: M, ML, L, XL
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40''
Rim strip
Bontrager TLR
Max tire size
Frame: 29x2.60", Fork: See manufacturer

Drivetrain
Shifter
Shimano U6000, 10 speed
Rear derailleur
Shimano CUES U6000 GS
Crank
Shimano CUES U6000, 30T, 55mm chainline, 170mm length
Bottom bracket
Shimano BB-MT501 BSA
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed
Chain
Shimano LG500
Pedal
Nylon platform
Max chainring size
1x: 34T, min 28T

Components
Saddle
Bontrager Verse P3, steel rails
*Seatpost
Size: S
TranzX JD-YSI34, 150mm travel, internal routing, 31.6mm, 456mm length
Size: M, ML
TranzX JD-YSI34, 170mm travel, internal routing, 31.6mm, 500mm length
Size: L, XL
TranzX JD-YSI34, 200mm travel, internal routing, 31.6mm, 565mm length
*Handlebar
Size: S
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
Size: M, ML, L, XL
Bontrager Comp, alloy, 31.8mm, 40mm rise, 780mm width
Grips
Trek Line Comp, nylon lock-on
*Stem
Size: S
Bontrager Comp, 31.8mm, 7 degree, 35mm length
Size: M, ML, L, XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Headset
FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown
Brake rotor
Shimano RT10, CenterLock, 180 mm
Brake Set
Shimano MT200 hydraulic disc
Rotor size
Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer

Weight
Weight
M - 14.53 kg / 32.04 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
