Rail+ 8 Gen 5

Frame
Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armor, Boost148, 12mm thru axle, 160mm travel
*Fork
Size: S
RockShox Lyrik, Delta RC, DebonAir+, tapered steerer, 44 mm offset, Boost 110, 15 mm Maxle Stealth, 160 mm travel
Size: M, L, XL
RockShox Lyrik, Delta RC, DebonAir+, tapered steerer, 44mm offset, Boost 110, 15mm Maxle Stealth, 160mm travel
Shock
RockShox Super Deluxe, Linear XL, 205mm x 65mm

Wheels
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost148, 12mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
*Tire
Size: S
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50"
Size: M, L, XL
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50"
Tire part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tire size
Frame: 27.5x2.60", Fork: See manufacturer

E-system
Battery
Bosch PowerTube 800Wh, smart system
Charger
Bosch standard 4A, 110V, smart system
Controller
Bosch System Controller Kiox400C, smart system
Motor
Bosch Performance Line CX (Europe and APAC: 25 km/h, US and ROW: 20 mph / 32 km/h)
E-bike Classification
Class 1

Drivetrain
Shifter
SRAM Eagle 70, 12 speed
Rear derailleur
SRAM Eagle 70, T-Type
Crank
FSA alloy, 160mm length
Chain ring
SRAM T-Type, 34T, steel
Cassette
SRAM Eagle XS-1270, T-Type,10-52, 12 speed
Chain
SRAM Eagle 70, T-Type, 12 speed
Pedal
Nylon platform
Max chainring size
1x: 36T

Components
Saddle
Bontrager Verse P3, steel rails
*Seatpost
Size: S
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length
Size: M
Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length
Size: L, XL
Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 5150mm length
Grips
Trek Line Comp, nylon lock-on
Stem
Bontrager Elite, 35mm, 0 degree, 45mm length
Brake
Shimano MT620 hydraulic disc
Brake rotor
Shimano RT66, 6-bolt, 203mm
Rotor size
Max brake rotor sizes - Frame: 220mm, Fork: see fork manufacturer

Accessories
Fender
Trek custom fender

Weight
Weight
M - 24.68 kg / 54.42 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
