Procaliber 9.5 Gen 3

Frame
OCLV Mountain Carbon, IsoBow, tapered head tube, guided internal routing, rack & accessory mounts, balanced post mount brake, UDH, Boost148
Fork
RockShox Judy GOLD, Solo Air spring, TurnKey lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 120mm travel

Wheels
Hub front
Shimano TC500 alloy, centerlock, 110x15mm thru axle
Hub rear
Shimano TC500 alloy, centerlock, 148x12mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve
Spokes
14g stainless steel, black
Tire
Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40"
Rim strip
Bontrager TLR
Max tire size
Frame: 29x2.40", Fork: See manufacturer

Drivetrain
Shifter
Shimano Deore M6200
Rear derailleur
Shimano Deore M6200, long cage
*Crank
Size: S, M, ML
Shimano MT520, 32T, 55mm chainline, 170mm length
Size: L, XL
Shimano MT520, 32T, 55mm chainline, 175mm length
Bottom bracket
Shimano MT500, 92mm, PressFit
Cassette
Shimano M6200, 10-51, 12 speed
Chain
Shimano Deore M6100, 12 speed
Max chainring size
1x: 38T

Components
Saddle
Verse Short, steel rails, 145mm width
*Seatpost
Size: S
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length
Size: M, ML, L
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 410mm length
Size: XL
Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length
*Handlebar
Size: S
Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
Size: M, ML, L, XL
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
Grips
Trek Line Comp, nylon lock-on
*Stem
Size: S
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: M, ML
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: L
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: XL
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Headset
FSA IS-2, 1-1/8" top, 1.5" bottom
*Brake rotor
Size: S, M, ML, L, XL
Shimano RT10, CenterLock, 160 mm
Size: L, XL
Shimano RT10, CenterLock, 180 mm
Brake Set
Shimano MT200 hydraulic disc
Rotor size
Max brake rotor sizes - Frame: 180mm, Fork: see fork manufacturer

Weight
Weight
M - 12.73 kg / 28.07 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
