Orbea
2024
Orca M30i 105 Di2
Orca M30i 105 Di2
Couldn't load pickup availability
Pick up could take up to 10 days
Pick up could take up to 10 days
Not all our bikes are stored at our retail location so in store pick up for bikes could take up to 10 days.
Please contact the store for more information on estimated pick up ETA.
Don't see what you want?
Don't see what you want?
Other colour and size options might be available for speical order.
Contact us for more information.
The New Orbea Orca Isn’t Just Light.
It is 6.7 kg of climbing technology designed to change how you reach the top. The feeling of a bike this light and efficient is unbeatable, and this instant acceleration, vibration absorption and responsive handling come from a frame which knows where it needs to be light and where it needs to be stiff. Welcome the ultimate climbing machine!
Achieving Orca´s light weight required many marginal gains, focusing on the details and using the best materials across the range. Considering the bike as a package means working with component and wheel designers right from the start to optimize stiffness and weight. But having the lightest bike is worth nothing if it isn’t stiff and efficient. When we designed Orca, we started with a target rigidity to ensure that even the strongest climbers could be sure of efficient power transmission. Then we designed Orca to be as light as possible without compromising that number.
Our clever frame design means that stiff doesn't have to be uncomfortable. Rounder frame sections help reduce vibrations, saving energy on longer rides and offering you an advantage on that final climb. Wider clearance allows for tires of up to 32 mm, maximizing traction and compliance. Modern road riders have discovered the advantages of bigger tires on rougher surfaces.
Share










Details
Specifications
Frame - Carbon: Orbea Orca carbon OMR 2026, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.
Fork - Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.
Shifters - Shimano 105 Di2 R7170, 2x12-speed
Front Derailleur - Shimano 105 Di2 R7150
Rear Derailleur - Shimano 105 Di2 R7150, 12-speed
Cassette - Shimano 105 R7100, 11-34T
Chain - Shimano M6100
Crankset - Shimano 105 R7100 34x50t
Bottom Bracket - BB386
Brakes - Shimano 105 R7170, Hydr. Disc Brake
Wheelset - Alloy, Tubeless, 700c, 19c, 28H
Tires - Continental Grand Prix Foldable 700x28c
Handlebar -OC Road Performance RP31, Reach 80, Drop 125
Bar Tape - Orbea Anti-Slippery/Shock Proof
Stem - OC Road Performance RP23, -5º
Headset - FSA 1-1/2" Integrated Aluminium Cup
Saddle - Fizik Aliante R5
Seatpost - SP 0.2 Carbon, 27.2mm, Setback 20
We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification. Specifications may not be as shown in photo.
Shipping
This bike is not eligible for shipping
Size Chart

Geometry Chart
